Performance characteristics:
The driving is directly driven by the motor motor, the whole machine has high efficiency and prolongs the working time;
The fork frame has good strength, and the whole life is high;
Walking device with full height, tilting, overloading, anti-pinch, smart charging, emergency descent, etc.
Configure one-key brake function, optional folding guardrail and semi-rotary door;
Intelligent diagnosis display, easy maintenance.
Details：
Specifications
| Item | Unit | GTJZ0607HD |
| Platform capacity | Kg | 230 |
| Extendable platform | Kg | 113 |
| Max. working height | m | 7.8 |
| Max. platform height | m | 5.8 |
| Length(L) | mm | 1860 |
| Width(W) | mm | 760 |
| Height (guardrail up) | mm | 2180 |
| Height (guardrail down) | mm | 1840 |
| Platform size | mm | 1670*740 |
| Extendable platform | mm | 900 |
| Min. Ground clearance | mm | 83 |
| Wheel base | mm | 1360 |
| Min. Turning radius (inner wheels) | mm | 0 |
| Min. Turning radius (outer wheels) | mm | 1640 |
| Lifting motor | V/Kw | 24/2 |
| Travel speed (folded) | Km/h | 4.5 |
| Travel speed (raised) | Km/h | 0.8 |
| Rising/decline speed | mm/sec | 84/38 |
| Battery | V/Ah | 4x6/210 |
| Charger | V/A | 24/25 |
| Grade ability | % | 25 |
| Max. working | 。 | 2 - 3 |
| Overall weight | kg | 1415 |
